The Total Data Connect Cellular Z Gateway is a cellular-based, remote monitoring system that connects to a cellular network via GSM or CDMA.
Connect wireless sensors to the Cellular Gateway to remotely monitor temperature, humidity, and more, and configure alerts when conditions fall outside of your set ranges.
Product SKU: SKU: TM-CELL600-WS
Key Features
- Plug & Play - No IT required
- Add up to 24 Wireless Sensors
- Includes Backup Battery (24-48 hrs)
- GSM & CDMA Available
Specifications
- Product Code: TM-CELL600-WS
- English Dimensions: 6.62” x 3.30” x 1.10”
- Metric Dimensions: 169 x 84 x 28
- Weight: 6.7 ounces (190 grams)
- Network Requirements: LTE Cellular Wireless Signal Coverage Area
- Battery-Backup: 24-48 Hours
- Device Operating Range: 15ºC to +35ºC (+59ºF to +95ºF)
- Temperature Sensor Range: -20ºC to +60ºC (-4ºF to +140ºF)
- Temperature error (*according to the sensor manufacturer): ± 0.5ºC (± 1.0ºF) between -10ºC and 60ºC
- Power Source: 5V 1A
- Maximum Wireless Sensors: 24
- Internal Battery: 3.7V Li-Ion Rechargeable
- Communications: Quad Band
- Data Log Format: Excel
- Warranty: 1 Year
For more information, please download the
Total Data Connect Remote Monitoring Brochure.
